Features
- Machine tapped fixture holes, adjustable mounting plate for additional substrate thickness
- Slots retain slider plate and guide it in a straight motion
- Internal rails guide slider plate for smooth mounting adjustability in wall substrates from 1/2 to 1-3/8 in thick and ceiling substrates from 1/2 to 1-5/32 in
- Square corner design allows easy wall cut-in
- Molded spline device holes for quick device screw installation in wall boxes and machine tapped threads for ceiling fixture support in round ceiling boxes
- Slider plate holds screws in ready position to enable contractor to mount boxes faster
- Fan support product has steel bracket and mounting bolts for secure paddle fan mounting
- Heavy-duty non-slip pad to ensure box and slider assembly solidly hold mounted position
- Tested to hold 50 lb hung on box to simulate power cord pull-out strength
Specifications
| Brand | ALLIED MOULDED PRODUCTS |
|---|---|
| Model # | SB=CB |
| Length | 8.313 in |
| Width | 5.875 in |
| Height | 12.25 in |
| Weight | 0.33 lbs |
| UPC | 085339945123 |
| SKU | 3825114 |
